RF103-5 - Teledyne Technologies

RF103-5 Details

• Manufacturer Part Number:

  RF103-5

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mexico, USA

• ECCN Code:

  EAR99

• Manufacturer:

  Teledyne Technologies Inc

• YTEOL:

  7

• Additional Feature:

  ELECTRICAL LIFE: 10000000 AT LOW LEVEL AND CONTACT VOLTAGE(DC)-MAX: 0.01 MA AT 10 MV

• Body Breadth:

  9.53 mm

• Body Height:

  10.03 mm

• Body Length or Diameter:

  9.53 mm

• Coil Current(DC)-Max:

  0.05 A

• Coil Operate Voltage(DC):

  3.6 V

• Coil Power:

  250 mW

• Coil Resistance:

  100 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  6 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  9.53mm x 9.53mm x 10.03mm

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  RF RELAY

• Release Time:

  3 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Switching Time:

  6 ms

• Termination Type:

  SOLDER
