RF1V-2A2B-D12 - Idec

RF1V-2A2B-D12 Details

• Manufacturer Part Number:

  RF1V-2A2B-D12

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  IDEC Corporation

• YTEOL:

  5.5

• Additional Feature:

  SOCKET MOUNTABLE

• Body Breadth:

  13 mm

• Body Height:

  24 mm

• Body Length or Diameter:

  40 mm

• Coil Current(DC)-Max:

  0.03 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  360 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  400 Ω

• Coil Voltage(DC)-Max:

  13.2 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  6A@250VAC

• Contact Current(AC)-Max:

  6 A

• Contact Current(DC)-Max:

  6 A

• Contact (DC) Max Rating R Load:

  6A@30VDC

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER TIN OXIDE

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  10

• Operate Time:

  20 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  40mm X 13mm X 24mm

• Reference Standard:

  CSA; EN; TUV; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  4 FORM A, B

• Relay Function:

  4PST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  20 ms

• Surface Mount:

  NO

• Terminal Length:

  0.0035052070104140214 inch

• Termination Type:

  SOLDER
