The recommended PCB layout involves using a 4-layer board with a solid ground plane, and placing thermal vias under the device to dissipate heat. A thermal pad on the bottom of the package should be connected to a thermal plane on the PCB.
Optimization involves using a combination of simulation tools and empirical methods to find the optimal impedance matching networks. Qorvo provides a reference design and simulation models to aid in the design process.
The device should be operated within the recommended temperature range of -40°C to 85°C, and the junction temperature should be kept below 150°C. Additionally, the device should be protected from electrostatic discharge and voltage stresses.
Stability can be ensured by following the recommended circuit topology, using a low-pass filter at the output, and adding resistive feedback to reduce the gain at high frequencies. Additionally, the device should be biased correctly and the input and output impedances should be matched.
The device has built-in ESD protection, but handling precautions should still be taken to prevent damage. These include using an anti-static wrist strap, handling the device by the package and not the pins, and storing the device in an anti-static bag.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
RFPA3800TR13 Overview
Use the download button to access the RFPA3800TR13 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like RFPA3,
or try a keyword search, such as RF/Microwave Amplifiers
About Qorvo
Qorvo is a prominent American semiconductor company that specializes in the design and manufacturing of radio frequency (RF) solutions. The company was formed in 2015 through the merger of TriQuint Semiconductor and RF Micro Devices. Qorvo's product portfolio encompasses a wide range of RF components and semiconductor technologies used in various applications, including wireless communications, aerospace and defense, and IoT (Internet of Things) devices.
