RFSA3513TR7 - RF Micro

RFSA3513TR7 Details

• Manufacturer Part Number:

  RFSA3513TR7

• Part Life Cycle Code:

  Transferred

• Package Description:

  3 X 3 MM, 0.85 MM HEIGHT, GREEN, QFN-16

• HTS Code:

  8542.39.00.01

• Manufacturer:

  RF Micro Devices Inc

• JESD-30 Code:

  S-XQCC-N16

• Length:

  3 mm

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Seated Height-Max:

  0.9 mm

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Telecom IC Type:

  TELECOM CIRCUIT

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  3 mm
