RHF1201KSO2 - STMicroelectronics

RHF1201KSO2 Details

• Manufacturer Part Number:

  RHF1201KSO2

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOIC

• Package Description:

  LEAD FREE, HERMETIC SEALED, SOP-48

• Pin Count:

  48

• ECCN Code:

  3A001.a.2.c

• HTS Code:

  8542.39.00.30

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Analog Input Voltage-Max:

  2 V

• Converter Type:

  ADC, PROPRIETARY METHOD

• JESD-30 Code:

  R-PDSO-G48

• Length:

  15.57 mm

• Linearity Error-Max (EL):

  0.041%

• Number of Analog In Channels:

  1

• Number of Bits:

  12

• Number of Functions:

  1

• Number of Terminals:

  48

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Bit Code:

  BINARY, 2S COMPLEMENT BINARY

• Output Format:

  PARALLEL, WORD

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HSSOP

• Package Equivalence Code:

  SSOP48,.48

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH

• Qualification Status:

  Not Qualified

• Sample Rate:

  50 MHz

• Sample and Hold / Track and Hold:

  SAMPLE

• Seated Height-Max:

  2.72 mm

• Supply Current-Max:

  2.5 mA

• Supply Voltage-Nom:

  2.5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  MILITARY

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.635 mm

• Terminal Position:

  DUAL

• Total Dose:

  300k Rad(Si) V

• Width:

  9.652 mm
