RJ-5G-SX-D-DPLX-LX-R-A - Cotsworks

RJ-5G-SX-D-DPLX-LX-R-A Details

• Manufacturer Part Number:

  RJ-5G-SX-D-DPLX-LX-R-A

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  PACKAGE-11

• Manufacturer:

  COTSWORKS LLC

• YTEOL:

  3

• Body Breadth:

  13.72 mm

• Body Height:

  9.75 mm

• Body Length or Diameter:

  23.27 mm

• Connection Type:

  ARINC 801

• Data Rate (Rx):

  5000 Mbps

• Data Rate (Tx):

  5000 Mbps

• Emitter/Detector Type:

  VCSEL

• Fiber Optic Device Type:

  TRANSCEIVER

• Fiber Type:

  50/125, 62.5/125, MMF

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Operating Wavelength-Max:

  860 nm

• Operating Wavelength-Min:

  840 nm

• Operating Wavelength-Nom:

  850 nm

• Optical Power Output-Nom:

  0.5 mW

• Return Loss-Min:

  12 dB

• Sensitivity:

  -14 dBm

• Supply Voltage-Max:

  3.47 V

• Supply Voltage-Min:

  3.14 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  NO
