RJHSE-5384 - Amphenol

RJHSE-5384 Details

• Manufacturer Part Number:

  RJHSE-5384

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  India

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  7 Weeks

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  8

• Additional Feature:

  WITH LED

• Board Mounting Option:

  PEG

• Body Breadth:

  0.53 inch

• Body Depth:

  0.62 inch

• Body Length:

  0.65 inch

• Body/Shell Style:

  JACK

• Connector Type:

  RJ CONNECTOR

• Contact Finish Mating:

  GOLD (50) OVER NICKEL (50)

• Contact Finish Termination:

  MATTE TIN OVER NICKEL

• Contact Gender:

  FEMALE

• Contact Material:

  PHOSPHOR BRONZE

• Contact Pattern:

  RECTANGULAR

• Contact Style:

  TELCOM, MODULAR

• DIN Conformance:

  NO

• Empty Shell:

  NO

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Force-Max:

  22.24 N

• Insulator Material:

  POLYETHYLENE

• JESD-609 Code:

  e3

• MIL Conformance:

  NO

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Option 2:

  MOUNTING FLANGE

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number Of PCB Rows:

  2

• Number of Ports:

  1

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  1.78 mm

• Plating Thickness:

  50u inch

• Polarization Key:

  POLARIZED HOUSING

• Reference Standard:

  UL

• Shell Finish:

  TIN

• Shell Material:

  STAINLESS STEEL

• Terminal Length:

  0.1 inch

• Terminal Pitch:

  2.03 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  8

• UL Flammability Code:

  94V-0
