RK49 - SANKEN ELECTRIC CO.

RK49 Details

• Manufacturer Part Number:

  RK49

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  AXIAL DIODE

• Package Description:

  AXIAL PACKAGE-2

• Pin Count:

  2

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Date Of Intro:

  1990-06-01

• Manufacturer:

  Sanken Electric Co Ltd

• YTEOL:

  0

• Application:

  GENERAL PURPOSE

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  0.81 V

• JESD-30 Code:

  O-PALF-W2

• Non-rep Pk Forward Current-Max:

  60 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  3.5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  90 V

• Reverse Recovery Time-Max:

  0.1 µs

• Surface Mount:

  NO

• Technology:

  SCHOTTKY

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL
