RP132S341D-E2-FE - Nisshinbo

RP132S341D-E2-FE Details

• Manufacturer Part Number:

  RP132S341D-E2-FE

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Nisshinbo Micro Devices

• YTEOL:

  10

• Dropout Voltage1-Max:

  0.68 V

• Dropout Voltage1-Nom:

  0.46 V

• Input Voltage-Max:

  6.5 V

• Input Voltage-Min:

  1.4 V

• JESD-30 Code:

  R-PDSO-G6

• JESD-609 Code:

  e3

• Length:

  5.02 mm

• Load Regulation-Max(%):

  0.06%

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  6

• Output Current1-Max:

  1 A

• Output Voltage1-Max:

  3.4646 V

• Output Voltage1-Min:

  3.3354 V

• Output Voltage1-Nom:

  3.4 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HSOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG

• Peak Reflow Temperature (Cel):

  260

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  1.85 mm

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.905 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10

• Voltage Tolerance-Max:

  1.9%

• Width:

  3.9 mm
