RP60Q-11005SRUWB/P - RECOM Power

RP60Q-11005SRUWB/P Details

• Manufacturer Part Number:

  RP60Q-11005SRUWB/P

• Part Life Cycle Code:

  Active

• Package Description:

  DMA,

• Reach Compliance Code:

  Unknown

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, CSA, EN, IEC, UL

• Efficiency (Main Output):

  89%

• Input Voltage-Max:

  160 V

• Input Voltage-Min:

  14 V

• Input Voltage-Nom:

  110 V

• JESD-30 Code:

  R-PDMA-P10

• Length:

  57.9 mm

• Line Regulation-Max:

  0.1%

• Load Regulation-Max:

  0.1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  12 A

• Output Voltage-Max:

  5.5 V

• Output Voltage-Min:

  4 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER VOLTAGE; OVER CURRENT; SHORT CIRCUIT; OVER TEMPERATURE

• Ripple Voltage (Main Out):

  0.0265125 Vrms

• Screening Level:

  EN/IEC/UL 62368-1

• Seated Height-Max:

  13.2 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  3.81 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  60 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.115 s

• Width:

  36.8 mm
