RPA30-2405SAW-HC Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  RECOM Power Inc recommends a PCB layout with a large copper area connected to the module's thermal pad to ensure good heat dissipation. A minimum of 2 oz copper thickness is recommended, and the copper area should be connected to a heat sink or a metal plate for further heat dissipation.
• Can I use this module in a high-vibration environment?
  Yes, the RPA30-2405SAW-HC is designed to withstand high vibrations. However, it's recommended to follow the recommended PCB layout and mounting guidelines to ensure the module is securely attached to the PCB. Additionally, the module's connectors should be securely fastened to prevent damage.
• How do I ensure electromagnetic compatibility (EMC) with this module?
  To ensure EMC, RECOM Power Inc recommends following the recommended PCB layout and using a metal enclosure to shield the module. Additionally, the module's input and output cables should be properly shielded and routed to minimize electromagnetic interference.
• What is the recommended input fuse rating for this module?
  RECOM Power Inc recommends using a fuse with a rating of 2-3 times the maximum input current of the module. For the RPA30-2405SAW-HC, the recommended fuse rating is 6-10 A.
• Can I use this module in a redundant configuration?
  Yes, the RPA30-2405SAW-HC can be used in a redundant configuration. However, it's recommended to follow the recommended PCB layout and ensure that the modules are properly isolated from each other to prevent damage in case of a fault.
