RECOM Power Inc recommends a PCB layout with a large copper area connected to the module's thermal pad to ensure good heat dissipation. A minimum of 2 oz copper thickness is recommended, and the copper area should be connected to a heat sink or a metal plate for further heat dissipation.
Yes, the RPA30-2412DAW/P is designed to withstand vibrations up to 10G peak acceleration, making it suitable for use in industrial and transportation applications. However, it's recommended to follow proper mounting and screwing procedures to ensure the module is securely fastened to the PCB or chassis.
To ensure EMC, RECOM Power Inc recommends following proper PCB layout and design guidelines, such as keeping sensitive analog circuits away from the DC-DC converter, using a common-mode choke, and adding EMI filters if necessary. Additionally, the module's metal case should be connected to the system's chassis ground to reduce radiated emissions.
The maximum allowable capacitance on the output of the RPA30-2412DAW/P is 2200uF. Exceeding this value may cause instability or oscillation in the output voltage. It's recommended to follow the recommended output capacitance values specified in the datasheet to ensure stable operation.
Yes, the RPA30-2412DAW/P can be used in a redundant or parallel configuration to achieve higher power output or redundancy. However, it's recommended to follow proper design and layout guidelines to ensure that the modules are properly synchronized and that the output voltages are properly balanced.
