RPMH3.3-1.5 - RECOM Power

RPMH3.3-1.5 Details

• Manufacturer Part Number:

  RPMH3.3-1.5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  EN

• Efficiency (Main Output):

  73%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  5 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  S-MBGA-N25

• Length:

  12.19 mm

• Line Regulation-Max:

  3%

• Load Regulation-Max:

  0.8%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  25

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1.5 A

• Output Voltage-Max:

  3.63 V

• Output Voltage-Min:

  2.64 V

• Output Voltage-Nom:

  3.3 V

• Package Body Material:

  METAL

• Package Code:

  LGA

• Package Equivalence Code:

  LGA25,5X5,90

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Protections:

  OVER CURRENT; SHORT CIRCUIT; OVER TEMPERATURE

• Ripple Voltage (Main Out):

  0.024745 Vrms

• Screening Level:

  EN 62368-1

• Seated Height-Max:

  4 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  2.29 mm

• Terminal Position:

  BOTTOM

• Total Power Output-Max:

  4.95 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.02 s

• Width:

  12.19 mm
