The thermal resistance of the RQ1E070RPFRATR is not explicitly stated in the datasheet, but it can be estimated to be around 2.5°C/W based on similar packages from ROHM Semiconductor.
While the RQ1E070RPFRATR has a maximum operating temperature of 150°C, it's essential to consider the derating curves and thermal management to ensure reliable operation in high-temperature environments.
To ensure reliability, follow the recommended operating conditions, storage conditions, and handling procedures outlined in the datasheet. Additionally, consider implementing a robust design, using proper thermal management, and performing thorough testing and validation.
The recommended land pattern for the RQ1E070RPFRATR can be found in the ROHM Semiconductor's package drawing or in the IPC-7351 standard. It's essential to follow the recommended land pattern to ensure proper soldering and to prevent thermal and mechanical stress.
The RQ1E070RPFRATR has a maximum voltage rating of 70V. While it can be used in high-voltage applications, it's crucial to ensure that the voltage rating is not exceeded and to consider the derating curves, especially in high-temperature environments.
