RRW30120-110 - Renesas Electronics

Description: The RRW30120 is a programmable USB Power Delivery (USB PD) controller with extended power range (EPR) support for powersource applications. It integrates a secondaryside regulation controller, interface protocol controller, and USB VBUS NFET driver into a single IC. The device supports EPR up to 48V output.An internal MCU and hardware interface manage the USB PD protocol, enabling rapid charging for any USB PDenabled sink device, such as mobile devices, notebook PCs, monitors, and power tools. Positioned on

Download RRW30120-110 Model

Schematic
symbols

PCB
footprints

3D
models

Alert me if there are changes to this RRW30120-110 model

Email notifications will be applied after download.

Send part feedback

Symbol

RRW30120-110 - Renesas Electronics - PCB symbol

PCB Footprints

RRW30120-110 - Renesas Electronics PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - QFN-16.....

3D Models

RRW30120-110 - Renesas Electronics - 3D model - Quad Flat No-Lead - QFN-16.....

Datasheet Download Datasheet
Stock & Prices Price & Stock for RRW30120-110
Part Number RRW30120-110
Manufacturer Renesas Electronics
Pin Count 17
Part Category Integrated Circuit
Package Category Quad Flat No-Lead
Footprint Name Quad Flat No-Lead - QFN-16.....
Released Date Mar 31, 2026
Last Modified Date Mar 31, 2026 5:07 AM UTC
Pinout / Pin List Click Here (Member Only)

RRW30120-110 Details

Manufacturer Part Number:
RRW30120-110
Manufacturer:
Renesas Electronics Corporation

Trust Checks

Manufacturer Collaborated

System Verified

Community Approved

RRW30120-110 Overview

Use the download button to access the RRW30120-110 schematic symbol, PCB footprint, and 3D model.
