RS-18 - Well Buying

RS-18 Details

• Manufacturer Part Number:

  RS-18

• Part Life Cycle Code:

  Contact Manufacturer

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.20

• Manufacturer:

  Well Buying Industrial Co Ltd

• Actuator Type:

  ROTARY

• Body Height:

  9.4996 mm

• Body Length or Diameter:

  16.4084 mm

• Center Contact Material:

  BRASS

• Center Contact Plating:

  SILVER

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Rating R Load:

  0.5A@30VDC

• Contact Resistance:

  0.025 mΩ

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  BRASS

• End Contact Plating:

  SILVER

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Positions:

  8

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• PCB Hole Count:

  9

• Surface Mount:

  NO

• Switch Function:

  SP8T

• Switch Type:

  ROTARY SWITCH

• Terminal Length:

  0.15 inch

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
