RSH3-2415D/H3 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  RECOM Power Inc recommends a PCB layout with a large copper area connected to the module's thermal pad to ensure good heat dissipation. A minimum of 2 oz copper thickness is recommended, and the copper area should be connected to a heat sink or a metal plate for further heat dissipation.
• Can I use this module in a high-vibration environment?
  Yes, the RSH3-2415D/H3 is designed to withstand high-vibration environments. However, it's recommended to follow the recommended PCB layout and mounting guidelines to ensure the module is securely attached to the PCB and can withstand vibrations up to 10G.
• What is the maximum allowable capacitance for the output filter?
  The maximum allowable capacitance for the output filter is 100uF. Exceeding this value may cause instability or oscillation in the output voltage.
• Can I use this module in a humid or wet environment?
  The RSH3-2415D/H3 is designed to operate in a dry environment with a relative humidity of up to 60%. If the module is to be used in a humid or wet environment, it's recommended to apply a conformal coating to protect the module from moisture.
• What is the recommended input fuse rating?
  The recommended input fuse rating is 2A slow-blow or 1A fast-acting fuse. This is to protect the module from input overvoltage and overcurrent conditions.
