S-80815CNNB-B8A-T2 - ABLIC Inc.

S-80815CNNB-B8A-T2 Details

• Manufacturer Part Number:

  S-80815CNNB-B8A-T2

• Rohs Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOIC

• Package Description:

  TSOP, SOT-343R

• Pin Count:

  4

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  ABLIC Inc.

• YTEOL:

  0

• Additional Feature:

  MNL RST:N;PW FL IO:N;PRG RST DLY:N;WD:N;WDO:N;WWD:N

• Adjustable Threshold:

  NO

• Analog IC - Other Type:

  VOLTAGE DETECTOR

• JESD-30 Code:

  R-PDSO-G4

• Length:

  2 mm

• Number of Functions:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSOP

• Package Equivalence Code:

  SOT-343R

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, THIN PROFILE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.1 mm

• Supply Current-Max (Isup):

  0.0024 mA

• Supply Voltage-Max (Vsup):

  10 V

• Supply Voltage-Min (Vsup):

  0.95 V

• Supply Voltage-Nom (Vsup):

  1.2 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.3 mm

• Terminal Position:

  DUAL

• Threshold Voltage-Nom:

  +1.5V

• Width:

  1.25 mm
