S28HS01GTGZBHI030 - Infineon

S28HS01GTGZBHI030 Details

• Manufacturer Part Number:

  S28HS01GTGZBHI030

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  12

• Clock Frequency-Max (fCLK):

  200 MHz

• JESD-30 Code:

  S-PBGA-B24

• JESD-609 Code:

  e1

• Length:

  8 mm

• Memory Density:

  1073741824 bit

• Memory IC Type:

  FLASH

• Memory Width:

  8

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  24

• Number of Words:

  134217728 words

• Number of Words Code:

  128000000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  128MX8

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VBGA

• Package Equivalence Code:

  BGA24,5X5,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY THIN PROFILE

• Parallel/Serial:

  SERIAL

• Peak Reflow Temperature (Cel):

  260

• Programming Voltage:

  1.8 V

• Seated Height-Max:

  1 mm

• Serial Bus Type:

  OSPI

• Supply Voltage-Max (Vsup):

  2 V

• Supply Voltage-Min (Vsup):

  1.7 V

• Supply Voltage-Nom (Vsup):

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Type:

  NOR TYPE

• Width:

  6 mm

• Write Protection:

  HARDWARE
