SAM9X60D1G-I/4FB - Microchip

Description: Microprocessors - MPU SAM9X60 System-In-Package (SIP) MPU

Download SAM9X60D1G-I/4FB Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
SAM9X60D1G-I/4FB - Microchip - PCB symbol
click to zoom
PCB Footprints
SAM9X60D1G-I/4FB - Microchip PCB footprint - BGA - BGA - TFBGA233
click to zoom
3D Models
SAM9X60D1G-I/4FB - Microchip - 3D model - BGA - TFBGA233
click to zoom

SAM9X60D1G-I/4FB Details

  • Manufacturer Part Number:

    SAM9X60D1G-I/4FB

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Pin Count:

    233

  • Manufacturer Package Code:

    TFBGA-233

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    5A992.C

  • HTS Code:

    8542.31.00.01

  • Factory Lead Time:

    13 Weeks

  • Date Of Intro:

    2019-09-23

  • Manufacturer:

    Microchip Technology Inc

  • YTEOL:

    19

  • uPs/uCs/Peripheral ICs Type:

    MICROPROCESSOR, RISC

SAM9X60D1G-I/4FB Frequently Asked Questions (FAQs)

  • The maximum operating frequency of the SAM9X60D1G-I/4FB is 600 MHz.
  • The SAM9X60D1G-I/4FB has 1 GB of flash memory.
  • The SAM9X60D1G-I/4FB has 4 GB of RAM.
  • Yes, the SAM9X60D1G-I/4FB supports Linux and other operating systems.
  • The power consumption of the SAM9X60D1G-I/4FB varies depending on the operating frequency and other factors, but it is typically in the range of 1-2 watts.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

SAM9X60D1G-I/4FB Overview

Use the download button to access the SAM9X60D1G-I/4FB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SAM9X, or try a keyword search, such as Microprocessors

About Microchip

Microchip Technology Inc. is a leading manufacturer of microcontrollers and semiconductor devices for a wide range of applications in the aerospace, automotive, consumer electronics, industrial, and medical industries. Alongside a comprehensive product portfolio, Microchip Technology Inc. also provides easy-to-use development tools that enable engineers to create optimal designs quickly with minimal iterations to reduce risk while lowering total system costs to market. Headquartered in Chandler, Arizona, th
