SBC847BDW1T1G - onsemi

SBC847BDW1T1G Details

• Manufacturer Part Number:

  SBC847BDW1T1G

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SC-88/SC70-6/SOT-363 6 LEAD

• Pin Count:

  6

• Manufacturer Package Code:

  419B-02

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Manufacturer:

  onsemi

• YTEOL:

  7

• Collector Current-Max (IC):

  0.1 A

• Collector-Emitter Voltage-Max:

  45 V

• Configuration:

  SEPARATE, 2 ELEMENTS

• DC Current Gain-Min (hFE):

  200

• JESD-30 Code:

  R-PDSO-G6

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  2

• Number of Terminals:

  6

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  NPN

• Power Dissipation-Max (Abs):

  0.38 W

• Reference Standard:

  AEC-Q101

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  AMPLIFIER

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  100 MHz
