SCM1256MF - SANKEN ELECTRIC CO.

SCM1256MF Details

• Manufacturer Part Number:

  SCM1256MF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Date Of Intro:

  2018-03-28

• Manufacturer:

  Sanken Electric Co Ltd

• YTEOL:

  0

• Analog IC - Other Type:

  3-PHASE BRUSHLESS DC MOTOR CONTROLLER

• JESD-30 Code:

  R-XDFM-T33

• Number of Functions:

  1

• Number of Terminals:

  33

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -30 °C

• Output Current-Max:

  30 A

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DFM

• Package Equivalence Code:

  MODULE,33LEAD,1.3

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Supply Voltage-Max (Vsup):

  16.5 V

• Supply Voltage-Min (Vsup):

  13.5 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Temperature Grade:

  OTHER

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL
