SCR410T-K03-05 - Murata Electronics

Description: Gyroscope X (Pitch) ±300 13Hz ~ 300Hz SPI 16-SOIC

Download SCR410T-K03-05 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
SCR410T-K03-05 - Murata Electronics - PCB symbol
click to zoom
PCB Footprints
SCR410T-K03-05 - Murata Electronics PCB footprint - Other - Other - SCC400T
click to zoom
3D Models
SCR410T-K03-05 - Murata Electronics - 3D model - Other - SCC400T
click to zoom

SCR410T-K03-05 Details

  • Manufacturer Part Number:

    SCR410T-K03-05

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    End Of Life

  • Package Description:

    SOIC-16

  • ECCN Code:

    EAR99

  • HTS Code:

    9031.80.80.85

  • Factory Lead Time:

    10 Weeks

  • Manufacturer:

    Murata Manufacturing Co Ltd

  • YTEOL:

    1

  • Body Breadth:

    7.65 mm

  • Body Height:

    2.3 mm

  • Body Length or Diameter:

    10.4 mm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    110 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    3-STATE

  • Output Type:

    DIGITAL VOLTAGE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    SOP16,.4

  • Package Shape/Style:

    RECTANGULAR

  • Sensors/Transducers Type:

    ACCELEROMETER/GYROSCOPE

  • Supply Voltage-Max:

    3.6 V

  • Supply Voltage-Min:

    3 V

  • Surface Mount:

    YES

  • Technology:

    MEMS

SCR410T-K03-05 Frequently Asked Questions (FAQs)

  • Murata provides a recommended PCB layout and land pattern in their application notes and design guides. It's essential to follow these guidelines to ensure optimal performance, minimize parasitic inductance, and reduce electromagnetic interference (EMI).
  • The selection of input and output capacitors depends on the specific application requirements, such as voltage rating, capacitance value, and ESR. Murata recommends using capacitors with a voltage rating of at least 1.5 times the input voltage and a capacitance value that meets the required ripple current and output voltage regulation. Consult the datasheet and application notes for more information.
  • The maximum ambient temperature for the SCR410T-K03-05 is 85°C. As the ambient temperature increases, the converter's efficiency and output power may decrease. It's essential to ensure proper airflow and heat dissipation to maintain optimal performance and prevent overheating.
  • The SCR410T-K03-05 has built-in overcurrent protection (OCP) and short-circuit protection (SCP). However, it's recommended to add external protection components, such as fuses or PTC thermistors, to ensure reliable operation and prevent damage to the converter and surrounding components.
  • The recommended input voltage range for the SCR410T-K03-05 is 3.0V to 5.5V. Operating outside this range may affect the converter's efficiency, output voltage regulation, and reliability. It's essential to ensure the input voltage is within the recommended range to maintain optimal performance.
