SDT-S-103DMR,000 - TE Connectivity

SDT-S-103DMR,000 Details

• Manufacturer Part Number:

  SDT-S-103DMR,000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  10 mm

• Body Height:

  25 mm

• Body Length or Diameter:

  24 mm

• Coil Current(DC)-Max:

  0.18 A

• Coil Operate Voltage(DC):

  2.25 V

• Coil Power:

  540 mW

• Coil Release Voltage(DC):

  0.3 V

• Coil Resistance:

  17 Ω

• Coil Voltage(DC)-Max:

  3 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  10A@250VAC

• Contact Current(AC)-Max:

  10 A

• Contact Current(DC)-Max:

  10 A

• Contact (DC) Max Rating R Load:

  10A@30VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER TIN OXIDE

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  15 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -30 °C

• Packing Method:

  TUBE

• Physical Dimension:

  24mm x 10mm x 25mm

• Reference Standard:

  CQC; TUV; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  5 ms

• Sealing:

  RT2; RT3

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT
