SEAFP-50-01-S-10-RA-WT-GP - SAMTEC

SEAFP-50-01-S-10-RA-WT-GP Frequently Asked Questions (FAQs)

• What is the recommended torque for the screws on this connector?
  The recommended torque for the screws on SEAFP-50-01-S-10-RA-WT-GP is 1.5-2.5 in-lbs (0.17-0.28 Nm) according to Samtec's application notes.
• Can I use this connector in a high-vibration environment?
  Yes, the SEAFP-50-01-S-10-RA-WT-GP is designed to withstand high-vibration environments. It meets the IEC 61373 Cat 2 vibration standard, which means it can operate in environments with vibrations up to 15 g.
• Is this connector suitable for use in harsh environments, such as those with high temperatures or humidity?
  The SEAFP-50-01-S-10-RA-WT-GP is designed for use in harsh environments. It has a operating temperature range of -55°C to 125°C and can withstand humidity up to 95% RH. However, it's recommended to consult Samtec's environmental testing reports for specific details.
• What is the mating cycle life of this connector?
  The SEAFP-50-01-S-10-RA-WT-GP has a mating cycle life of 500 cycles minimum, according to Samtec's specifications.
• Can I use this connector with a PCB thickness other than 1.57 mm?
  While the SEAFP-50-01-S-10-RA-WT-GP is designed for use with 1.57 mm thick PCBs, Samtec does offer variations for other PCB thicknesses. Consult Samtec's documentation or contact their support team for more information.
