- Part Number SF2388E
- Manufacturer Murata Electronics
- Pin Count 6
- Part Category Filter
- Package Category Other
- Footprint Name Other - SM3030-6
- Released Date Dec 10, 2020
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
SF2388E Details
-
Manufacturer Part Number:
SF2388E
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Obsolete
-
Reach Compliance Code:
Compliant
-
Manufacturer:
Murata Manufacturing Co Ltd
-
YTEOL:
0
-
Additional Feature:
TR, 7/13 INCH; TEMPERATURE OF -40 TO 105 ALSO AVAILABLE
-
Center or Cutoff Frequency (fo/fc):
1176.45 MHz
-
Filter Type:
SAW FILTER
-
Height:
1.3 mm
-
Input Impedance:
50 OHM
