SF64G-TP - MCC

SF64G-TP Details

• Manufacturer Part Number:

  SF64G-TP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  Micro Commercial Components

• YTEOL:

  5.99

• Additional Feature:

  HIGH RELIABILITY

• Application:

  SUPER FAST RECOVERY

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  0.975 V

• JEDEC-95 Code:

  DO-201AD

• JESD-30 Code:

  O-PALF-W2

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Pk Forward Current-Max:

  150 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  6 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Peak Reflow Temperature (Cel):

  260

• Rep Pk Reverse Voltage-Max:

  200 V

• Reverse Current-Max:

  5 µA

• Reverse Recovery Time-Max:

  0.035 µs

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL

• Time@Peak Reflow Temperature-Max (s):

  10
