SH050M0680B5S-1325 - Yageo Group

SH050M0680B5S-1325 Details

• Manufacturer Part Number:

  SH050M0680B5S-1325

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ,

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00.20

• Manufacturer:

  YAGEO Corporation

• YTEOL:

  0

• Capacitance:

  680 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Diameter:

  13 mm

• Dielectric Material:

  ALUMINUM (WET)

• ESR:

  860 mΩ

• JESD-609 Code:

  e3

• Leakage Current:

  0.343 mA

• Length:

  25 mm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Package Shape:

  CYLINDRICAL PACKAGE

• Package Style:

  Radial

• Packing Method:

  BULK

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  50 V

• Ripple Current:

  860 mA

• Surface Mount:

  NO

• Tan Delta:

  0.12

• Terminal Finish:

  MATTE TIN

• Terminal Pitch:

  5 mm

• Terminal Shape:

  WIRE
