SI8946AB-IS - Skyworks

SI8946AB-IS Details

• Manufacturer Part Number:

  SI8946AB-IS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SOIC-8

• HTS Code:

  8542.39.00.30

• Manufacturer:

  Skyworks Solutions Inc

• Analog Input Voltage-Max:

  0.0625 V

• Analog Input Voltage-Min:

  -0.0625 V

• Converter Type:

  ADC, DELTA-SIGMA

• JESD-30 Code:

  R-PDSO-G8

• Length:

  4.9 mm

• Linearity Error-Max (EL):

  0.032%

• Number of Analog In Channels:

  1

• Number of Bits:

  1

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  BINARY

• Output Format:

  SERIAL

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP8,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Sample Rate:

  10 MHz

• Seated Height-Max:

  1.75 mm

• Supply Current-Max:

  8.9 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  3.9 mm
