Part Image

SiC431AED-T1-GE3 - Vishay

Description: Switching Voltage Regulators 4.5-24V 24A 50uA microBUCK MLP44-24

Download SiC431AED-T1-GE3 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
SiC431AED-T1-GE3 - Vishay - PCB symbol
click to zoom
PCB Footprints
SiC431AED-T1-GE3 - Vishay PCB footprint - Other - Other - PowerPAK MLP44-24L
click to zoom
3D Models
SiC431AED-T1-GE3 - Vishay - 3D model - Other - PowerPAK MLP44-24L
click to zoom

SiC431AED-T1-GE3 Details

  • Manufacturer Part Number:

    SIC431AED-T1-GE3

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    MLP44-24

  • Country Of Origin:

    Japan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    16 Weeks

  • Manufacturer:

    Vishay Intertechnologies

  • YTEOL:

    8

  • Analog IC - Other Type:

    SWITCHING REGULATOR

  • Control Mode:

    VOLTAGE-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    24 V

  • Input Voltage-Min:

    4.5 V

  • Input Voltage-Nom:

    12 V

  • JESD-30 Code:

    S-XQCC-N24

  • Length:

    4 mm

  • Number of Functions:

    1

  • Number of Terminals:

    24

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    24 A

  • Output Voltage-Max:

    21.6 V

  • Output Voltage-Min:

    0.6 V

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    VQCCN

  • Package Equivalence Code:

    LCC24,.16SQ,18

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, VERY THIN PROFILE

  • Seated Height-Max:

    0.8 mm

  • Surface Mount:

    YES

  • Switcher Configuration:

    BUCK

  • Switching Frequency-Max:

    1000 kHz

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.45 mm

  • Terminal Position:

    QUAD

  • Width:

    4 mm

SiC431AED-T1-GE3 Frequently Asked Questions (FAQs)

  • The recommended PCB footprint for the SIC431AED-T1-GE3 is a standard SOD-123 package footprint with a minimum pad size of 1.5mm x 1.5mm and a thermal pad size of 2.5mm x 2.5mm.
  • To ensure reliability in high-temperature applications, it is recommended to follow proper thermal management practices, such as providing adequate heat sinking, using thermal interface materials, and ensuring good airflow around the device.
  • The maximum allowed voltage derating for the SIC431AED-T1-GE3 is 10% of the maximum rated voltage, which is 120V for this device.
  • Yes, the SIC431AED-T1-GE3 can be used in switching applications, but it is recommended to follow proper switching frequency and duty cycle guidelines to ensure reliable operation.
  • To handle ESD protection for the SIC431AED-T1-GE3, it is recommended to follow proper ESD handling procedures, such as using ESD-safe workstations, wearing ESD-protective clothing, and using ESD-protective packaging.

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

SiC431AED-T1-GE3 Overview

Use the download button to access the SiC431AED-T1-GE3 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SiC43, or try a keyword search, such as Switching Regulator or Controllers
