SIC438CED-T1-GE3 - Vishay

Description: Switching Voltage Regulators 4.5 - 28V 8A MICROBUCK

Download SIC438CED-T1-GE3 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
SIC438CED-T1-GE3 - Vishay PCB footprint - Other - Other - SIC438CED-T1-GE3-5
click to zoom
3D Models
SIC438CED-T1-GE3 - Vishay  - 3D model - Other - SIC438CED-T1-GE3-5
click to zoom

SIC438CED-T1-GE3 Details

  • Manufacturer Part Number:

    SIC438CED-T1-GE3

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    16 Weeks

  • Manufacturer:

    Vishay Intertechnologies

  • YTEOL:

    7.7

  • Analog IC - Other Type:

    SWITCHING REGULATOR

  • Control Mode:

    VOLTAGE-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    28 V

  • Input Voltage-Min:

    3 V

  • Input Voltage-Nom:

    12 V

  • JESD-30 Code:

    S-XQCC-N24

  • Length:

    4 mm

  • Number of Functions:

    1

  • Number of Terminals:

    24

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    8 A

  • Output Voltage-Max:

    25.2 V

  • Output Voltage-Min:

    0.6 V

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    VQCCN

  • Package Equivalence Code:

    LCC24,.16SQ,18

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, VERY THIN PROFILE

  • Seated Height-Max:

    0.8 mm

  • Supply Current-Max (Isup):

    0.12 mA

  • Surface Mount:

    YES

  • Switcher Configuration:

    BUCK

  • Switching Frequency-Max:

    1000 kHz

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.45 mm

  • Terminal Position:

    QUAD

  • Width:

    4 mm

SIC438CED-T1-GE3 Frequently Asked Questions (FAQs)

  • The recommended PCB footprint for the SIC438CED-T1-GE3 is a standard TO-252 (D-PAK) footprint with a minimum pad size of 2.5 mm x 2.5 mm and a thermal pad size of 4.5 mm x 4.5 mm.
  • To ensure reliable soldering, use a soldering iron with a temperature range of 250°C to 260°C, and apply a solder flux to the pins. Avoid applying excessive force or pressure, which can damage the device.
  • The maximum allowed power dissipation for the SIC438CED-T1-GE3 is 150 W at a case temperature of 25°C. However, it's recommended to derate the power dissipation to ensure reliable operation and prevent thermal runaway.
  • The SIC438CED-T1-GE3 is a commercial-grade device and may not meet the requirements for high-reliability or aerospace applications. For such applications, consider using a device with a higher reliability rating, such as a MIL-PRF-19500 or NASA-approved device.
  • Handle the SIC438CED-T1-GE3 with ESD-sensitive precautions, such as using an ESD wrist strap or mat, and store the device in an ESD-protective package. Avoid touching the pins or exposing the device to static electricity.
