SiT8009BI-21-33E-125.000000G - SiTime

SiT8009BI-21-33E-125.000000G Details

• Manufacturer Part Number:

  SIT8009BI-21-33E-125.000000G

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Malaysia, Taiwan, Thailand

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  SiTime Corporation

• YTEOL:

  6

• Additional Feature:

  ENABLE/DISABLE FUNCTION; ALSO COMPATIBLE WITH HCMOS O/P

• Fall Time-Max:

  2 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  20%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  125 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVCMOS

• Output Load:

  15 pF

• Output Low Current-Max:

  4 mA

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  DILCC4,.1,83

• Packing Method:

  TR

• Physical Dimension:

  3.2mm x 2.5mm x 0.75mm

• Rise Time-Max:

  2 ns

• Supply Current-Max:

  7.5 mA

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  NICKEL PALLADIUM GOLD
