SJ1-3515N - Same Sky

SJ1-3515N Details

• Manufacturer Part Number:

  SJ1-3515N

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Same Sky

• Audio Type:

  STEREO

• Body Breadth:

  0.236 inch

• Body Depth:

  0.689 inch

• Body Length:

  0.453 inch

• Body/Shell Style:

  JACK

• Configuration:

  1X1 HORIZONTAL

• Connector Type:

  3.5MM AUDIO

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Finish Termination:

  Tin (Sn)

• Contact Gender:

  FEMALE

• Contact Material:

  NOT APPLICABLE

• Contact Resistance:

  50 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  500VAC V

• Durability:

  5000 Cycles

• Insertion Force-Max:

  29.4 N

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE

• JESD-609 Code:

  e3

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Poles:

  3

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Rated Current (Signal):

  1 A

• Reference Standard:

  UL

• Terminal Length:

  0.118 inch

• Termination Type:

  SOLDER
