SK35GAL12T4 - Semikron

SK35GAL12T4 Details

• Manufacturer Part Number:

  SK35GAL12T4

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  SEMIKRON

• YTEOL:

  5.35

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  43 A

• Collector-Emitter Voltage-Max:

  1200 V

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• Gate-Emitter Thr Voltage-Max:

  6.5 V

• JESD-30 Code:

  R-XUFM-P16

• Number of Elements:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  N-CHANNEL

• Reference Standard:

  UL RECOGNIZED

• Surface Mount:

  NO

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UPPER

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  373 ns

• Turn-on Time-Nom (ton):

  53 ns

• VCEsat-Max:

  2.1 V
