SK60GAL125 - Semikron

SK60GAL125 Details

• Manufacturer Part Number:

  SK60GAL125

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CASE T18, SEMITOP 2, 7 PIN

• Pin Count:

  7

• Manufacturer Package Code:

  CASE T18

• ECCN Code:

  EAR99

• Manufacturer:

  SEMIKRON

• YTEOL:

  5

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  51 A

• Collector-Emitter Voltage-Max:

  1200 V

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-XUFM-X7

• Number of Elements:

  1

• Number of Terminals:

  7

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  N-CHANNEL

• Qualification Status:

  Not Qualified

• Reference Standard:

  UL RECOGNIZED

• Surface Mount:

  NO

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• VCEsat-Max:

  3.7 V
