SKIIP23NAB126V1 - Semikron

SKIIP23NAB126V1 Details

• Manufacturer Part Number:

  SKIIP23NAB126V1

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Pin Count:

  42

• ECCN Code:

  EAR99

• Manufacturer:

  SEMIKRON

• YTEOL:

  3

• Additional Feature:

  HIGH RELIABILITY

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  41 A

• Collector-Emitter Voltage-Max:

  1200 V

• Configuration:

  COMPLEX

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-XUFM-X42

• JESD-609 Code:

  e3/e4

• Number of Elements:

  7

• Number of Terminals:

  42

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  N-CHANNEL

• Qualification Status:

  Not Qualified

• Reference Standard:

  UL RECOGNIZED

• Surface Mount:

  NO

• Terminal Finish:

  TIN/SILVER

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  565 ns

• Turn-on Time-Nom (ton):

  115 ns

• VCEsat-Max:

  2.1 V
