SLB9665TT20FW563XUMA3 - Infineon

Description: Security ICs / Authentication ICs TPM

Download SLB9665TT20FW563XUMA3 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
SLB9665TT20FW563XUMA3 - Infineon PCB footprint - Small Outline Packages - Small Outline Packages - TSSOP_2020
click to zoom
3D Models
SLB9665TT20FW563XUMA3 - Infineon  - 3D model - Small Outline Packages - TSSOP_2020
click to zoom

SLB9665TT20FW563XUMA3 Details

  • Manufacturer Part Number:

    SLB9665TT20FW563XUMA3

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Not Recommended

  • Package Description:

    TSSOP-28

  • HTS Code:

    8542.31.00.30

  • Factory Lead Time:

    53 Weeks, 1 Day

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    3

  • JESD-30 Code:

    R-PDSO-G28

  • JESD-609 Code:

    e3

  • Length:

    9.7 mm

  • Moisture Sensitivity Level:

    3

  • Number of Terminals:

    28

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -20 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSSOP

  • Package Equivalence Code:

    TSSOP28,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

  • Seated Height-Max:

    1.1 mm

  • Supply Voltage-Max:

    3.6 V

  • Supply Voltage-Min:

    3 V

  • Supply Voltage-Nom:

    3.3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    4.4 mm

  • uPs/uCs/Peripheral ICs Type:

    CRYPTOGRAPHIC AUTHENTICATOR

SLB9665TT20FW563XUMA3 Frequently Asked Questions (FAQs)

  • Infineon provides a recommended PCB layout guide in their application note AN215, which includes guidelines for component placement, routing, and thermal management to ensure optimal performance and reliability.
  • The SLB9665TT20FW563XUMA3 has a thermal pad on the bottom of the package, which should be connected to a thermal plane on the PCB. Additionally, Infineon recommends using a heat sink or thermal interface material to improve heat dissipation.
  • The input capacitors should be low-ESR, high-frequency capacitors with a minimum capacitance of 10uF and a voltage rating of at least 25V. X7R or X5R dielectric capacitors are recommended.
  • Infineon provides a troubleshooting guide in their application note AN217, which includes steps for identifying and resolving common issues with the SLB9665TT20FW563XUMA3.
  • The output capacitors should be low-ESR, high-frequency capacitors with a minimum capacitance of 10uF and a voltage rating of at least 2x the output voltage. Ceramic capacitors with an X7R or X5R dielectric are recommended.
