SLG46120P - Renesas Electronics

SLG46120P Details

• Manufacturer Part Number:

  SLG46120P

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China, Taiwan

• HTS Code:

  8542.31.00.55

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  6

• Additional Feature:

  CAN ALSO OPERATE AT 3.3V OR 5V SUPPLY

• Architecture:

  PLA-TYPE

• In-System Programmable:

  NO

• JESD-30 Code:

  S-XQCC-N12

• JTAG BST:

  NO

• Length:

  2 mm

• Number of Dedicated Inputs:

  1

• Number of I/O Lines:

  9

• Number of Inputs:

  10

• Number of Macro Cells:

  12

• Number of Outputs:

  9

• Number of Terminals:

  12

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  1 DEDICATED INPUTS, 9 I/O

• Output Function:

  MACROCELL

• Package Body Material:

  UNSPECIFIED

• Package Code:

  VQCCN

• Package Equivalence Code:

  LCC12,.08SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Programmable Logic Type:

  OT PLD

• Seated Height-Max:

  0.6 mm

• Supply Voltage-Max:

  1.89 V

• Supply Voltage-Min:

  1.71 V

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  2 mm
