SLG46867M - Renesas Electronics

SLG46867M Details

• Manufacturer Part Number:

  SLG46867M

• Brand Name:

  Renesas

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  MSTQFN

• Pin Count:

  20

• Country Of Origin:

  Taiwan

• HTS Code:

  8542.31.00.55

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  6

• Architecture:

  PAL-TYPE

• In-System Programmable:

  NO

• JESD-30 Code:

  R-XQCC-N20

• JTAG BST:

  NO

• Length:

  3 mm

• Moisture Sensitivity Level:

  1

• Number of Dedicated Inputs:

  1

• Number of I/O Lines:

  10

• Number of Inputs:

  11

• Number of Macro Cells:

  15

• Number of Outputs:

  11

• Number of Terminals:

  20

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  1 DEDICATED INPUTS, 10 I/O

• Output Function:

  MACROCELL

• Package Body Material:

  UNSPECIFIED

• Package Code:

  VQCCN

• Package Equivalence Code:

  LCC20,.06X.12,16

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER, VERY THIN PROFILE

• Programmable Logic Type:

  OT PLD

• Seated Height-Max:

  0.6 mm

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  2.3 V

• Supply Voltage-Nom:

  2.5 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  QUAD

• Width:

  1.6 mm
