SLG59H1008VTR - Renesas Electronics

SLG59H1008VTR Details

• Manufacturer Part Number:

  SLG59H1008VTR

• Brand Name:

  Renesas

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  STQFN-18 (1.6 x 3.0 mm)

• Package Description:

  STQFN-18

• Pin Count:

  18

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  7

• Additional Feature:

  CURRENT LIMIT:3.5A; THERMAL SHUTDOWN:125C; ADJUSTABLE CURRENT LIMIT

• Adjustable Threshold:

  YES

• Analog IC - Other Type:

  LOAD SWITCH

• JESD-30 Code:

  R-XQCC-N18

• Length:

  3 mm

• Moisture Sensitivity Level:

  1

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Terminals:

  18

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  VQCCN

• Package Equivalence Code:

  LCC18,.06X.12,16

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER, VERY THIN PROFILE

• Seated Height-Max:

  0.6 mm

• Supply Voltage-Max (Vsup):

  25.2 V

• Supply Voltage-Min (Vsup):

  10.8 V

• Supply Voltage-Nom (Vsup):

  12 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  QUAD

• Threshold Voltage-Nom:

  10.2

• Width:

  1.6 mm
