SLG7MD47679V footprint, schematic symbol and 3D model by Renesas Electronics

SLG7MD47679V - Renesas Electronics

Description: The SLG7MD47679 is a versatile H-Bridge motor driver solution, designed for high-voltage applications with configurable Pulse Width Modulation (PWM) macrocells and robust high-voltage outputs. With high voltage and current handling capabilities, it is ideal for complex motor or load drive applications, smart level translators, and managing high-voltage, high-current loads efficiently. Its compact design, low power consumption, and versatile functionality make it a perfect choice for modern electronics, prio

Download SLG7MD47679V Model

Schematic
symbols

PCB
footprints

3D
models

Symbol

click to zoom

PCB Footprints

SLG7MD47679V - Renesas Electronics PCB footprint - Other - Other - STQFN 20L 2.0 mm x 3.0 mm x 0.55 mm 0.4P FCD

click to zoom

3D Models

SLG7MD47679V - Renesas Electronics - 3D model - Other - STQFN 20L 2.0 mm x 3.0 mm x 0.55 mm 0.4P FCD

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for SLG7MD47679V
Part Number SLG7MD47679V
Manufacturer Renesas Electronics
Pin Count 24
Part Category Integrated Circuit
Package Category Other
Footprint Name Other - STQFN 20L 2.0 mm x 3.0 mm x 0.55 mm 0.4P FCD
Released Date Mar 10, 2025
Last Modified Date Mar 10, 2025 1:11 PM UTC
Pinout / Pin List Click Here (Member Only)

SLG7MD47679V Details

Manufacturer Part Number:
SLG7MD47679V
Manufacturer:
Renesas Electronics Corporation

Trust Checks

Manufacturer Collaborated

System Verified

Community Approved

SLG7MD47679V Overview

Use the download button to access the SLG7MD47679V schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like SLG7M, or try a keyword search, such as Motion Control Electronics
