SM28VLT32SHKN - Texas Instruments

SM28VLT32SHKN Details

• Manufacturer Part Number:

  SM28VLT32SHKN

• Brand Name:

  Texas Instruments

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  3A001.A.2.A

• HTS Code:

  8542.32.00.71

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Clock Frequency-Max (fCLK):

  1 MHz

• Data Polling:

  YES

• Endurance:

  1000 Write/Erase Cycles

• JESD-30 Code:

  R-CDFP-G14

• JESD-609 Code:

  e4

• Length:

  20 mm

• Memory Density:

  33554432 bit

• Memory IC Type:

  FLASH

• Memory Width:

  16

• Number of Functions:

  1

• Number of Terminals:

  14

• Number of Words:

  2097152 words

• Number of Words Code:

  2000000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  210 °C

• Operating Temperature-Min:

  -55 °C

• Organization:

  2MX16

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  DFP

• Package Equivalence Code:

  SOP14,1,40

• Package Shape:

  RECTANGULAR

• Package Style:

  FLATPACK

• Parallel/Serial:

  SERIAL

• Programming Voltage:

  1.8 V

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  3.05 mm

• Serial Bus Type:

  SPI

• Supply Current-Max:

  0.16 mA

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  3.1 V

• Supply Voltage-Nom (Vsup):

  1.9 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Gold (Au)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.02 mm

• Terminal Position:

  DUAL

• Toggle Bit:

  YES

• Type:

  NOR TYPE

• Width:

  8 mm

• Write Protection:

  HARDWARE
