Texas Instruments provides a recommended PCB layout for the SM320C6201GJCA20EP in the 'TMS320C62x/C67x PowerPAD Thermally Enhanced Package' application report (SLUA139). It includes guidelines for thermal vias, heat sinks, and PCB layer stackup.
Texas Instruments recommends using a boot loader that can handle errors and exceptions, such as the 'TMS320C62x/C67x Boot Loader' (SPRU613). Additionally, ensure that the boot process is robust against power-on reset, brown-out reset, and watchdog timer reset.
To minimize EMI and ensure EMC, follow the guidelines in the 'TMS320C62x/C67x EMI and EMC Considerations' application report (SLUA140). This includes using a solid ground plane, decoupling capacitors, and shielding, as well as following proper PCB layout and routing techniques.
Optimize performance by using the 'TMS320C62x/C67x Optimizing C/C++ Compiler Options' guide (SPRU615), which provides recommendations for compiler options, loop optimization, and cache usage. Additionally, consider using the 'TMS320C62x/C67x Cycle Accurate Simulator' (SPRU616) to simulate and optimize your code.
The SM320C6201GJCA20EP is rated for operation up to 125°C. However, high temperatures can affect the device's performance, power consumption, and reliability. Consult the 'TMS320C62x/C67x Reliability and High-Temperature Operation' application report (SLUA141) for guidelines on thermal management, derating, and reliability considerations.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
SM320C6201GJCA20EP Overview
Use the download button to access the SM320C6201GJCA20EP schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SM320,
or try a keyword search, such as Digital Signal Processors
