SM7720HEV-25.0M-T500 - Pletronics

SM7720HEV-25.0M-T500 Details

• Manufacturer Part Number:

  SM7720HEV-25.0M-T500

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LCC, 4 PIN

• Manufacturer:

  Pletronics Inc

• YTEOL:

  6.3

• Additional Feature:

  STANDBY; ENABLE/DISABLE FUNCTION

• Fall Time-Max:

  5 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  20%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Max:

  69.9 MHz

• Operating Frequency-Min:

  0.8 MHz

• Operating Frequency-Nom:

  25 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  CMOS

• Output Load:

  15 pF

• Package Body Material:

  CERAMIC

• Package Equivalence Code:

  DILCC4,.2,200

• Packing Method:

  TR, EMBOSSED, 7/10/13 INCH

• Physical Dimension:

  7.0mm x 5.0mm x 1.73mm

• Rise Time-Max:

  5 ns

• Screening Level:

  MIL-STD-883

• Supply Current-Max:

  35 mA

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  GOLD OVER NICKEL
