SM8S43A-Q - Bourns

SM8S43A-Q Details

• Manufacturer Part Number:

  SM8S43A-Q

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  14 Weeks

• Manufacturer:

  Bourns Inc

• YTEOL:

  7.5

• Additional Feature:

  PD-CASE

• Breakdown Voltage-Max:

  52.8 V

• Breakdown Voltage-Min:

  47.8 V

• Breakdown Voltage-Nom:

  50.3 V

• Case Connection:

  ANODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  DO-218

• JESD-30 Code:

  R-PSSO-C1

• Non-rep Peak Rev Power Dis-Max:

  6600 W

• Number of Elements:

  1

• Number of Terminals:

  1

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  8 W

• Reference Standard:

  AEC-Q101; IATF 16949; ISO 7637-2; ISO 16750-2

• Rep Pk Reverse Voltage-Max:

  43 V

• Reverse Current-Max:

  10 µA

• Reverse Test Voltage:

  43 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  C BEND

• Terminal Position:

  SINGLE
