For optimal performance, it's recommended to follow the PCB layout guidelines provided in the datasheet, ensuring a solid ground plane, and using thermal vias to dissipate heat. A minimum of 2oz copper thickness is recommended for the PCB.
To ensure EMC, follow the recommended PCB layout, use a shielded enclosure, and ensure proper grounding. Additionally, use EMI filters and shielding on I/O lines, and consider using a common-mode choke on the power lines.
Use a soldering iron with a temperature range of 250°C to 260°C, and a solder with a melting point of 217°C to 220°C. For rework, use a hot air gun with a temperature range of 250°C to 260°C, and a solder wick or desoldering braid to remove excess solder.
Handle the device in an ESD-controlled environment, using ESD-safe materials and tools. Store the device in its original packaging or an ESD-safe container, and ensure all personnel handling the device wear ESD-protective wrist straps or clothing.
The SMDA24C-8.TBT is designed to meet the reliability requirements of automotive and industrial applications. The device is rated for a minimum of 10 years of operation, with a predicted failure rate of <1% per 1,000 hours of operation.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
SMDA24C-8.TBT Overview
Use the download button to access the SMDA24C-8.TBT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SMDA2,
or try a keyword search, such as Transient Suppressors
