SMEJ76CA-TP - MCC

SMEJ76CA-TP Details

• Manufacturer Part Number:

  SMEJ76CA-TP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Micro Commercial Components

• YTEOL:

  7

• Breakdown Voltage-Max:

  95 V

• Breakdown Voltage-Min:

  85 V

• Breakdown Voltage-Nom:

  90 V

• Clamping Voltage-Max:

  135 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-F2

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  BIDIRECTIONAL

• Rep Pk Reverse Voltage-Max:

  76 V

• Reverse Current-Max:

  5 µA

• Reverse Test Voltage:

  76 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10
