The maximum frequency of operation for the SN7423N is typically around 30 MHz, but it can vary depending on the specific application and operating conditions.
To ensure reliable operation of the SN7423N in high-temperature environments, it's essential to follow proper thermal management practices, such as providing adequate heat sinking and ensuring good airflow around the device. Additionally, the device should be operated within its recommended operating temperature range of -40°C to 85°C.
The recommended power-on sequence for the SN7423N is to apply the power supply voltage (VCC) before applying any input signals. This helps to prevent unwanted latch-up or oscillation during power-up.
Yes, the SN7423N can be used in a 3.3V system, but it's essential to ensure that the input signals are within the recommended voltage range of 0.8V to 2.4V. Additionally, the output voltage levels may not be compatible with 3.3V logic, so level translation may be required.
To handle ESD protection for the SN7423N, it's recommended to follow proper ESD handling procedures, such as using an ESD wrist strap or mat, and ensuring that the device is stored in an ESD-protected environment. Additionally, the device should be handled by the body only, and not by the leads.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
SN7423N Overview
Use the download button to access the SN7423N schematic symbol, PCB footprint, and 3D model.
