The maximum clock frequency of the SN7493AN is 25 MHz, but it can vary depending on the specific application and operating conditions. It's recommended to check the device's timing specifications and perform thorough testing to ensure reliable operation at the desired clock frequency.
To ensure proper power supply and decoupling, connect the VCC pin to a stable 5V power supply, and decouple the power supply lines with 0.1uF ceramic capacitors as close to the device as possible. Additionally, use a 10uF electrolytic capacitor to filter out any noise or ripple on the power supply lines.
The recommended operating temperature range for the SN7493AN is 0°C to 70°C. However, the device can operate up to 125°C with reduced performance and reliability. It's essential to ensure that the device operates within the recommended temperature range to maintain its performance and longevity.
The asynchronous reset input (R) on the SN7493AN is active-low, meaning it should be connected to a logic low level to reset the device. When the reset input is asserted, the device will reset to its initial state, and all outputs will be cleared. It's essential to ensure that the reset input is properly debounced and synchronized with the clock signal to avoid any issues during reset.
The maximum output current that the SN7493AN can sink or source is 16mA. However, it's recommended to limit the output current to 10mA or less to ensure reliable operation and prevent overheating. If higher output currents are required, consider using an external buffer or driver.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
SN7493AN Overview
Use the download button to access the SN7493AN schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SN749,
or try a keyword search, such as Counters
