SP3491CN-L - MaxLinear, Inc.

Description: RS-422/RS-485 Interface IC RS485 10000 kbp 3.3V temp 0C to 70C

Download SP3491CN-L Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
SP3491CN-L - MaxLinear, Inc. PCB footprint - Small Outline Packages - Small Outline Packages - XR2211ACDTR-F
click to zoom
3D Models
SP3491CN-L - MaxLinear, Inc.  - 3D model - Small Outline Packages - XR2211ACDTR-F
click to zoom

SP3491CN-L Details

  • Manufacturer Part Number:

    SP3491CN-L

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    End Of Life

  • Package Description:

    NSOIC-14

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    16 Weeks

  • Manufacturer:

    MaxLinear Inc

  • YTEOL:

    0

  • Differential Output:

    YES

  • Driver Number of Bits:

    1

  • Input Characteristics:

    DIFFERENTIAL SCHMITT TRIGGER

  • Interface IC Type:

    LINE TRANSCEIVER

  • Interface Standard:

    EIA-485; EIA-422

  • JESD-30 Code:

    R-PDSO-G14

  • JESD-609 Code:

    e3

  • Length:

    8.65 mm

  • Number of Functions:

    1

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    70 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Receive Delay-Max:

    120 ns

  • Receiver Number of Bits:

    1

  • Seated Height-Max:

    1.75 mm

  • Supply Voltage-Max:

    3.6 V

  • Supply Voltage-Min:

    3 V

  • Supply Voltage-Nom:

    3.3 V

  • Surface Mount:

    YES

  • Technology:

    BICMOS

  • Temperature Grade:

    COMMERCIAL

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Transmit Delay-Max:

    60 ns

  • Width:

    3.9 mm

SP3491CN-L Frequently Asked Questions (FAQs)

  • For optimal performance, it is recommended to follow the PCB layout guidelines provided in the application note AN-215. Ensure a solid ground plane, use thermal vias, and keep the device away from heat sources. A 4-layer PCB with a dedicated power plane and a solid ground plane is recommended.
  • To optimize the SP3491CN-L for low power consumption, ensure that the device is operated at the lowest possible supply voltage (VCC) while maintaining the required output voltage. Disable any unused features, and use the power-down mode when not transmitting. Additionally, optimize the transmit frequency and data rate to minimize power consumption.
  • The SP3491CN-L has built-in ESD protection diodes on all pins. However, it is still recommended to follow proper ESD handling procedures during assembly and testing. For latch-up prevention, ensure that the device is powered up and down slowly, and avoid voltage spikes or transients on the power supply lines.
  • To troubleshoot issues with the SP3491CN-L, start by verifying the power supply voltage and ensuring that it is within the recommended range. Check the device's operating frequency and data rate settings. Use a logic analyzer or oscilloscope to monitor the device's output and input signals. Consult the datasheet and application notes for specific troubleshooting guidelines.
  • For testing and measurement, use a high-impedance probe or a 50-ohm terminated oscilloscope to measure the device's output signals. Ensure that the test equipment is properly calibrated and configured. Use a signal generator to provide a stable clock input, and verify the device's output frequency and amplitude. Consult the datasheet and application notes for specific test and measurement procedures.
